Soil-Max Tile Plows Make it Easy for Farmers of All Sizes to Install Their Own Tile Drainage.
Manufactured from T1 Steel, twice the tensile strength with half the weight.
Thinner profile shank = easier pulling.
Lifts soil through the entire soil profile to reduce drag on the tile plow.
Trapezoidal-shaped shear and contoured boots to match pipe size and maintain a perfectly formed trench from beginning to end for accurate drainage tile placement.
The patented Zero Deflection (ZD) produces better grade control, with the drainage tile exit point directly below the tile plow’s hinge point.
A proprietary proportional valve makes crucial incremental adjustments to keep your tile plow on grade.
Convinced yet?
The Soil-Max Tile Plow Advantage
Tile Plow Stats
-
Pull Type
2 meters (6.5 ft) maximum working depth.
Easy single-pin connection to hitch.
Needs a minimum of an 11 ton (25,000 lbs) tractor.
Installation of 100mm to 290mm (4” to 10”) drainage tile by quickly changing poly-sided boots and shear.
Single-point hydraulic hook-up to tractor.
A proprietary down pressure manifold puts only necessary pressure on the wing wheels.
-
ZD1600 / 3-Point
1.6 meters (5.5 ft) working depth.
3-point linkage in Cat 3 or Cat 4 Narrow.
Needs a minimum of a 9 ton (20,000 lbs) tractor.
Installation of 65mm to 290mm (2” to 10”) drainage tile by quickly changing poly-sided boots and shear.
-
ZD1200 / ZD48
Needs a minimum of a 4.5 ton (10,000 lbs) tractor.
Thinner profile shank (easier pulling through soil)
1.2 meters (4 ft) maximum working depth.
Install 65mm to 130mm (2” to 4”) drainage tile by quickly changing boots and shear.
Zero deflection produces better grade control with the drainage tile exit point directly below the hinge point of the tile plow.
Proprietary proportional valve to make crucial incremental adjustments to keep your tile plow on grade.
Poly sides shed dirt and make for an easier pull.
